Electrical Systems Operation & Diagnosis Module (602)
Subaru Tribeca Combination
Meter
DASH
The Sweep and sequential illumination of the
Combination Meter can be turned on and off.
– Ignition key to accessory
– Press the Trip Meter stalk 3 times (or until
the “S” appears in the Trip Meter display).
– Press and hold the Trip Meter for more
than 2 seconds to change the “I” or “S”
setting.
“S-On” indicates the sweep function is on.
“S-off” indicates the sweep function is off.
“I-on” indicates the sequential illumination
is on. “I-off” indicates the sequential
illumination is off.
The Combination Meter D check procedure is
accomplished by performing the following steps:
(begin the first push of the Trip Meter stalk
before the sweep function ends)
– Ignition off
– Ignition on, small light (parking lights from
the head light switch) on.
– Push Trip Meter 3 times
– Small light off
– Push Trip Meter 3 times
– Small light on
– Push Trip Meter 3 times
DTCs can be viewed on the Trip Meter by
following the steps above but push the Trip Meter
4 times in each step instead of 3 times.
Toggle through the DTCs by pressing the Trip
Meter stalk. The first set of codes will be for the
engine, followed by the transmission DTCs. The
ABS codes C- - - will be viewed on the Trip Meter
display, however, the new ABS/HCU does not
communicate DTCs to the Combination Meter.
Combination Meter D Check
Procedure of change over to DIAG mode.
Note: The number of times you push
the Trip Meter Knob on the
combination Meter is different
between the “DTC reading mode”
and the “self diagnosis mode”
1) Within 3 second after the IG switch turned
on, turn the illumination switch on, then
perform the following steps 2 to 4 within
the followed 10 seconds.
2) Push the “trip knob” 3 times while
illumination switch ON.
3) Turn the illumination switch off, then push
the trip knob 4 times. (3 times for Self
diagnosis mode)
4) Turn the illumination switch ON again,
push the trip knob 4 times. (3 times for
self diagnosis mode)
Now, the mode was changed to DTC
Reading mode or Self diagnosis mode of
the combination meter.
Note: The white diagnostic connector
at the fuse-box under the
instrumental panel is eliminated.
