28
June 2013
Electrical Systems Operation & Diagnosis Module (602)
Select Monitor
The Select Monitor will display analog and CAN data while viewing the Integ. Unit mode.
Examples of SSMIII BIU Data:
Analog data CAN data
BATT Voltage (Control) Key lock warning SW
BATT Voltage (Back up) Stop Light Switch
IG power supply voltage Front Fog lamp switch
ACC Voltage Rear Fog lamp switch*
Illumination VR voltage Lighting SW
Illumi. Output d-ratio Door key lock SW
Ambient temp sensor V Door unlock SW
Ambient temperature Passenger door SW
Fuel level voltage Rear right door SW
Fuel level resistance Rear left door SW
Key lock solenoid V Rear gate SW
Number of regist. Manual lock SW
Front wheel speed Manual unlock SW
NOTES:
