82
June 2013
Electrical Systems Operation & Diagnosis Module (602)
Other 2010MY and Newer
Electrical Advancements
Driver Window Switch
The driver side door window is now equipped
with an Auto Up feature that must initialized be
each time power is removed from the window
circuit or the battery is disconnected. Initialization
is performed by closing the window with driver’s
open/close switch and holding the switch in the
closed position after the window has reached
the fully closed position for at least 4 seconds.
Auto Up and Down are now initialized. The
driver window switch assembly contains the
circuitry that controls Auto Up and Down. An
Auto Reverse feature is incorporated that will
automatically open the window to about halfway
when an obstacle is detected in the window
opening as the window is closed. An increase
in amperage to the window motor signals Auto
Reverse to engage.
Inspection Mode Fuse Location
Defogger Switch
The windshield deicer is now prohibited from
activating in ambient temperatures above 41°F.
This feature can be defeated by pushing and
holding the front deicer switch for at least 4
seconds. The LED in the switch will blink when
the deicer activates.
The mirror heaters, (if equipped) are activated
with the rear defogger.
