Electrical Systems Operation & Diagnosis Module (602)
The Keyless Access and Push Button Start Remote key (KAC) can be used to open and close the
PRG if the ignition is in the off position. Press the PRG switch for more than 2 seconds to toggle
between the open and close operation. The PRG memory switch and the interior PRG opener/
closer switch are located to the lower left of the steering column.
KAC Remote Transmitter & Keyless Entry Key Interior PRG Open/Closer Switch
Gas Shock and PRG Connecting Rod
Operation Mode
The system only operates, when the vehicle status is “not moving” and the following conditions exist:
1. AT model: Shift lever is in P position.
2. MT model: Parking brake is applied.
3. If the rear gate is open and the vehicle starts to move, the PRG will not operate and
the gate will remain open. A caution buzzer alerts the driver that the rear gate is open.
4. If a switch is pushed while the rear gate is closed and the vehicle moves, the PRG will
not operate.
5. If the opener switch is pushed while the gate is opening, the gate operation is changed
towards the inverse direction and closes.
6. The doors must be unlocked (interior switch only).
7. Outside temperature is between -22° and 158° Fahrenheit.
