Electrical Systems Operation & Diagnosis Module (602)
Remote Key
Antenna
OscillatorKA CM BIU
Driver Door Lock Passenger Front Door Left Rear Door Right Rear Door Gate or Trunk Lock
Driver Door Touch Sensor
Passenger Door Touch Sensor
Rear Gate or Trunk Switch
Driver Door Lock Button or Sensor
Passenger Door Lock Button or Sensor
Rear Gate or Trunk Lock Button
Receiver
BRZ Unlock Touch Sensor
Legacy/Outback
Unlock Touch Sensor Lock Switch
BRZ Lock Sensor
Remote Key Location Keyless Access Function
Initial Contact Unlocking / Locking doors, Gate or Trunk
The touch sensors are one wire capacitance type sensors. Touching the sensor or sensor cover (door handle) changes the capacitance of the sensor circuit and determines the location and function to be performed.
