& Center and side ventilators
S04AA02
! Center ventilators
S04AA0201
Move the tab up and down or right and left
to adjust the flow direction.
! Side ventilators
S04AA0202
1) Open
2) Close
Move the tab up and down or right and left
to adjust the flow direction.
To open the ventilator, turn the side grille
open/close wheel upward to the “
” posi-
tion.
To close it, turn the wheel downward to the
“
” position.
Manual climate control sys-
tem (if equipped)
S04AB
& Control panel
S04AB01
1) Temperature control dial
2) Fan speed control dial
3) Air flow control dial
4) Air conditioner button
5) Air inlet selection button
6) Rear window defogger button (Refer to
the “
s03aoRear window defogger button”
section in chapter 3.)
