Chapter 4 Hardware and Software Configuration 91
About Internal Disk Drives
The Sun Fire 280R server supports up to two internal, hot-pluggable Fibre Channel-
Arbitrated Loop (FC-AL) disk drives. Drives are 3.5 inches wide and 1 inch high
(8.89 cm x 2.54 cm).
The drives are supported by the up to 106-Mbyte per second FC-AL interface on the
system’s main logic board. Both drives plug in to the two-disk backplane, which
mounts to the system’s chassis.
The following figure shows the system’s two internal disk drives. Disk drives are
numbered 0 and 1, with the 0 drive being the default system disk.
Internal drive 0
Internal drive 1
(option)
(default)
