203
APPENDIX
A
Connector Signal Descriptions
This appendix describes the Sun Fire 280R server main logic board connector signals
and pin assignments that are accessible from the back panel.
The following topics are covered in this appendix:
■ “Reference for the Serial Port A and B Connectors” on page 204
■ “Reference for the Twisted-Pair Ethernet (TPE) Connector” on page 206
■ “Reference for the UltraSCSI Connector” on page 208
■ “Reference for the Parallel Port Connector” on page 212
■ “Reference for the Fibre Channel-Arbitrated Loop (FC-AL) Port Connector” on
page 214
■ “Reference for the Universal Serial Bus (USB) Connectors” on page 215
