Appendix A Field-Replaceable Units A-3
1
TABLE A-1 Server FRU List
Item No. FRU
Replacement
Instructions Description Location
1 Motherboard
and chassis
assembly
Section 5.6,
“Replacing the
Motherboard and
Chassis” on
page 5-20
The motherboard and chassis are
replaced as a single assembly. The
motherboard is provided in different
configurations to accommodate the
different processor models (6 core
and 8 core).
MB
2 DIMMs Section 5.5,
“Replacing
DIMMs” on
page 5-14
Can be ordered in the following
sizes:
• 512 MB
•1GB
•2GB
See
TABLE 5-1
and FIGURE 5-11.
3 Fan tray
assembly
Section 5.2,
“Replacing the Fan
Tray Assembly” on
page 5-4
A single assembly containing 4 fans. FT0
4 Hard drives Section 5.4,
“Replacing a Hard
Drive” on page 5-7
One of the following configurations:
• One SATA disk drive, 3.5-inch
form factor
• Two SAS disk drives, 2.5-inch form
factor
HDD0
HDD1
5 Power supply
unit (PS)
Section 5.3,
“Replacing the
Power Supply” on
page 5-5
The power supply provides -3.3 Vdc
standby power at 3 @ 3 Amps and 12
Vdc at 25 Amps.
PS0
6 PCI-Express
card slot
Section 5.1,
“Replacing the
Optional PCI-
Express Card” on
page 5-2
Optional add-on express card. PCIE0
7 Clock battery Section 5.7,
“Replacing the
Clock Battery” on
page 5-22
The battery is located on the
motherboard.
MB/BAT
8 SEEPROM Remove and
replace the
socketed
SEEPROM.
The socketed SEEPROM contains the
MAC address and system
configuration information.
MB/SCC
