5-10 Sun Fire T1000 Server Service Manual • January 2007
6. Perform the procedures described in Chapter 6.
7. Perform the necessary administrative tasks to reconfigure the hard drive.
The procedures that you perform at this point depend on how your data is
configured. You might need to partition the drive, create file systems, or load data
from backups.
5.4.2 Replacing a Hard Drive in a Dual-Drive Assembly
5.4.2.1 Removing a Hard Drive in a Dual-Drive Assembly
1. Perform the procedures described in Chapter 4.
2. Disconnect the drive cable from the data and power connectors on the
motherboard (
FIGURE 5-8).
FIGURE 5-8 Location of Drive Power and Data Connectors on the Motherboard
Power
connector
Data connector (J5002)
Data connector (J5003)
