58 Sun Fire X4150, X4250 and X4450 Servers Windows Operating System Installation Guide • January 2009
■ The Adaptec Configuration Utility is a BIOS-based utility that enables you to
create and manage controllers, disk drives and other devices, and arrays using the
integrated RAID controller (Adaptec-based). If you use the BIOS Configuration
Utility to create arrays, the Sun StorageTek RAID Manager GUI detects those
arrays and displays them as logical drives in the GUI.
■ The arrconf command-line interface (CLI) can be used with the Sun StorageTek
SAS RAID HBA to perform many of the same tasks provided with the StorageTek
RAID Manager GUI.
Available documentation for the above components may be found on the Sun
documentation web site at:
http://docs.sun.com/app/docs/coll/dsk-cntrl
Using Intel NIC Teaming
Intel® PROSet for Windows Device Manager is an extension to the Windows Device
Manager. When you update the critical drivers for your Sun Fire server, Intel PROSet
software configuration tabs are automatically added to the network adapters listed
in Device Manager. Intel PROSet includes features such as teaming of your network
interface ports, fault tolerance, load balancing, link aggregation, and Virtual LAN
(VLAN) tagging.
Note – For information about identifying the active network connections on your
server, refer to Appendix A.
▼ To Access Intel NIC Teaming Configuration Settings
To access the functions available for your server’s network interface, do the
following:
1. From the Taskbar, click Start, and then click Run.
The run dialog box is displayed.
2. In the Open list, type devmgmt.msc, and then click OK.
The Device Manager dialog box is displayed.
3. Expand the Network adapters group and select the first adapter.
4. Right-click the selection and click Properties.
The adapter properties dialog box is displayed.
