880 SERIES
9.2 Maxxus Massage/Waterfall Selector Diagram
Massage Selector Operation
Rotate Massage Selectors 1 and 2 to divert water between designated
jet groups.
Massage Selectors (1-2)
• Massage Selector #1 controls pump #2.
• Massage Selector #2 controls pump #3.
Waterfall Selector (3)
• Waterfall Selector #3 controls circulation pump output to waterfall.
Continuously Powered Jets (4)
• Jets #4 are always on when jets pump #1 is running.
102
°
2
3
1
4
4
4
4
4
1b
1a
2a
2a
2a
2b
2b
a
a
b
b
1b 1b
1b
2b
2b
2b
3
