880 SERIES
9.8 Optima Massage/Waterfall Selector Diagram
Massage Selector Operation
Rotate Massage Selectors 1 and 2 to divert water between designated
jet groups.
Massage Selectors (1-2)
• Massage Selector #1 controls pump #1.
• Massage Selector #2 controls pump #2.
Waterfall Selector (3)
• Waterfall Selector #3 controls circulation pump output to waterfall.
Continuously Powered Jets (4-5)
• Jets #4 are always on when jets pump #1 is running.
• Jets #5 are always on when jets pump #2 is running.
