Users Guide
KEY UNIT SPECIFICATIONS
TABLETOP FOOTPRINT (L X W X H) 22.4x48.2x30.5 cm
UNIT WEIGHT 19.6 kg
INPUT VOLTAGE (SINGLE PHASE) 90-264 VAC
FREQUENCY RANGE 47-63 Hz
POWER FACTOR (TYP.) 0.95/230 VAC (0.98/115 VAC at Full Load)
OUTPUT VOLTAGE RANGE 0.10-5.00 V (0.01 V Intervals)
OUTPUT CURRENT RANGE 10.0-250 A
OUTPUT POWER RANGE 1.0-650 W
WELD TIME (EACH PULSE) 1-500 ms (1 ms intervals)
SINGLE AND DUAL PULSE YES
PULSE 1, PULSE 2 ENERGY ADJUSTMENT 0-100%
TYPICAL RISE TIME (TO MAX VOLTAGE) 10 ms
