Page | 12
Residual Current Monitoring
Unit
Integrated
Output Over Current
Protection
Integrated
Output Shorted Protection Integrated
Output Over Voltage
Protection
Integrated
Surge Protection DC Type II / AC Type II
Certifications and Standards
Grid Regulation
UL1741, IEEE1547, RULE21, VDE0126, AS4777, NRS2017,
G98,G99, IEC61683, IEC62116, IEC61727
Safety Regulation IEC2109-1, IEC62109-2
EMC EN61000-6-1, EN61000-6-3, FCC 15 Class B
General Data
Operating Temperature
Range
-25~60°C, >45°C Derating
Cooling Fan
Noise <30dB
Communication with BMS RS485; CAN
Weight 45kg
Size (Length x Width x
Height)
673 x 462 x 265mm
Protection Degree IP65
Installation Style Wall-mounted
Warranty 5 years
