LCDDISPLAY–LiquidDispensers
LCDDisplay
Ope ration Temperature
SureShotDispensingSystems®liquiddispensersuseaLiquidCrystalDispla y(LCD)inthe
upperleftcornerofthedispenserdoortoshowthecurrentdispenserfun ction. Note:notall
dispensershaveanLCD.
Informationisdisplayedintwoparts:
Operation– showsthecurrentoperatingfunctionofthedispenser
Temperature– showstheinternaltemperatureoftherefrigerationcompartment.(NOTE:thisis
thecompartmenttemperatureinCelsiusorFahrenheitdegrees,notproduct
temperature.)
Temperature:
Continuouslyshowstheinternaltemperaturestatusoftherefrigeratedproductcompartmentin
CelsiusorFahrenheitdegrees,atyourcompany’sspecifications.Thedisplaychangesevery3
seconds.
Examples: 37F 37degreesFahrenheit
(blank) refrigerationsystemoff
refrigerationsystemon
DEF def rostcycleinprogress
Operation:
PressthebuttontoSelectProduct.TheLCDshowstheoperationalstatusofthatproducttankor
case: 
Display OperationalStatus
SureShot 37F Indicatesthedispenserisreadytodispense
andtheinternalcompartmenttemperatureis37°Fahrenheit
CaseLow
TankLow
DispenserswithLowLevelIndicatorswilldisplaythismessageto
alertusersthattheproductvolumeinthe tankorca seislowandwill
soonneedtoberefilledorreplaced.
Productmaybedispensedwhileproductislow.
CaseEmpty
TankEmpty
Theproductcaseortankselectedisemptyandcannotdispense
product
TR1
TR2
TR3
Ifthevalvedoorisopenedandclosed,thedispenserresetsthe
productlevelforthecaseortankdispensedbythatvalve.This
displayshowsthatthelevelhasbeenresetforthetank/case
displayed.
SkimMilk
LowFat
Milk
Cream
Indicatestheproducttobedispensed.DisplayedafterProduct
Selectionbuttonispressed.
NOTE:Theseareexamples.AwidevarietyofSpecialtyDrinksmay
bedispensedtoyourcompany’sspecifications.
TopUp (X)
Small (S)
Medium (M)
Large (L)
ExtraLarge (XL)
PressthebuttontoSelectSize.TheLCDdisplaysthesizetobe
dispensedtoyourcompany’sspecifications:
extraportion/topup,small,medium,large,extralarge
NOTES:
· Oncetheproductisdispensed,theLCDcyclesbacktothebeginning:FreshDairy
· DisplayreturnstoSureShot,thedefaultdisplay,after3seconds.
SelectTank37F
