SureShot IntelliShot - Loading Bag in Box; Bag in Box Loading Steps

10
LOADING:BaginBox
· Productissuppliedinasanitaryprepackagedbaginaboxthatfitsintotherefrigerated
productcompartmentofthedispenser.
· Sanitizeyourhandsorwearcleanglovestoinstallthebaginboxanddeliverytube.
1. Openthedoortotherefrigeratedcompartment.
2. Openthevalvedoorbyunscrewingtheblack
knobinacounterclockwisemotiontoloosen
thescrew.
3. Loadthebaginboxdairyproductintothe
refrigeratedproductcompartmentonthe
ProductBoxRamp,withtheproductdelivery
tubefacingouttothefrontandcenteredinthe
dispensingvalve.
4. Makesuretherearenokinksortwistsin the
productdeliverytube.
5. Aligntheproductdeliverytubeinthecentral
verticalgrooveofthevalveblock. Donotpull
orstretchtheproductdeliverytube.
6. Closethevalvedoor,makingsuretheproduct
deliverytubeisintheverticalgrooveandisnot
kinkedorpinched.
7. Whileholdingthevalvedoorclosedwithone
hand,tightentheknobscrewinaclockwise
motionuntilthedoorissnug. Donotover
tightenthescrew.
8. Squeezetheproductdeliverytubejustbelow
thevalvewithallfingertips.
9. PCDispensers:Whilesqueezingthetube,
pressthe“small”productquantitybuttononthe
frontdoorbuttonpanelonceonly.Thiswill
causethevalvetooperateonceandrelieve
pressureinthetube.
SSDispensers: Whilesqueezingthetube,
holdtheleverdowntorelievepressureinthe
tube.
10. Usesharpscissorstocarefullycuttheproduct
deliverytubeata45°angleatamaximum
lengthof5/8”fromthebottomofthevalve
block. Discardthecutportionofthetube.
12. Closetherefrigeratedproductcompartment
door.
Thedispenserisreadyforuse.
