Surron HYPER BEE - Page 29

10.4
10.3
Please refer to page 10.4 Torque management.
Note: Items marked with “*” in the manual should use Kraft K-0609 (or similar products)
Maintenance Maintenance
Loca Tion Item Torque Specification Note
Hexagon socket-M6*20
Hexagon flange bolt--M8*20
Hexagon socket -M8*56
Hexagon socket -M8*42
Hexagon socket -M8*50
Left
A
B
D
C
H IE
G
F
J
C
D
Steering tube locking bolts
Front ＆ rear caliper installation screws
Controller installation screws
Rear wheel axle locking nuts
Handlebar clamp arch and
handlebar support installation screws
Motor reduction gearbox
front installation bolts
Motor reduction gearbox
rear installation screws
Front ＆ rear brake disc
installation screws
Rear shock absorber
installation screws bottom
Rear shock absorber
installation screws top
11-13N.m
45-50N.m
8-10N.m
10-12N.m
10-12N.m
25-28N.m
30-35N.m
30-35N.m
30-35N.m
55-60N.m
Hexagon socket pan head
cap bolt-M16*1*17.5
Hexagon socket pan head
cap screw-M5*10
Hexagon socket head
cap screws-M6*12
Hexagon flange locking nut
-M12*1.25
Torx hexagon flange screw
-M6*25
*
*
*
only for
handlebar
support
