Surron HYPER BEE - Page 30

10.6
10.5
Right
L
R
K
M N
O
P
Q
S
T
T
Maintenance Maintenance Maintenance Maintenance
Hexagon bolt-M6*16
Hexagon socket -M8*25
Hexagon socket -M8*20
Hexagon socket -M8*20
Hexagon socket -M5*18
Torx pan head bolt-M16*1.5*12
Hexagon socket -M5*18
10-12N.m
25-28N.m
10-12N.m
25-28N.m
45-50N.m
25-28N.m
8-10N.m
20-30N.m
8-10N.m
/
Loca Tion Item Torque Specification Note
Front sprocket installation bolts
Battery holder bar installation screws
Rear sprocket installation screws
Footpeg installation screws
Middle shaft bolts
Frame support bracket installation screws
Front fork locking screws
Front wheel axle locking bolts
Front wheel axle locking screws
Steering tube adjustment nuts
T-shaft bolt outer thread
-M24*1*8
Torx hexagon flange screw
-M6*16
Torx pan head bolt
-M10*1.25*30
Note: Items marked with “*” in the manual should use Kraft K-0609 (or similar products)
*
*
*
*
