Suzuki DR650SEM2 2021 - Page 16

15
RIGHT
CLAMP
Clamp the right switch wiring harness with strap.
A: Strap L:120 mm
B: Handlebars
C: Right switch wiring harness
LEFT
Clamp the left switch wiring harness and clutch lever
position switch lead wire with strap.
A: Strap L:120 mm
B: Handlebars
C: Left switch wiring harness
D: Clutch lever position switch lead wire
Fit the cable clip to the throttle cables.
A: Clip
B: Throttle cable (Pulling)
C: Throttle cable (Returning)
UP
