Engine Mechanical: 1D-69
Tightening Torque Specifications
B827H11407002
NOTE
The specified tightening torque is also described in the following.
“Engine Assembly Installation (Page 1D-9)”
Reference:
For the tightening torque of fastener not specified in this section, refer to “Tightening Torque List (LT-A400/F) in
Section 0C (Page 0C-9)”.
Special Tools and Equipment
Recommended Service Material
B827H11408001
Fastening part
Tightening torque
Note
N⋅mkgf-mlb-ft
Air cleaner box mounting bolt 7 0.7 5.0 )(Page 1D-5)
Engine mounting bracket bolt 28 2.8 20.0 )(Page 1D-9)
Cylinder head bolt (initial) 25 2.5 18.0 )(Page 1D-14)
Cylinder head bolt (Final) 37 3.7 26.5 )(Page 1D-14)
Cylinder head nut (8 mm) (Initial) 10 1.0 7.0 )(Page 1D-15)
Cylinder head nut (8 mm) (Final) 25 2.5 18.0 )(Page 1D-15)
Cylinder base nut 10 1.0 7.0 )(Page 1D-15)
Cam chain tensioner bolt 13 1.3 9.5 )(Page 1D-15)
Camshaft sprocket bolt 15 1.5 11.0 )(Page 1D-16)
Cylinder head cover bolt 10 1.0 7.0 )(Page 1D-18)
Cam chain tension adjuster bolt 10 1.0 7.0 )(Page 1D-19)
Cam chain tension adjuster spring holder bolt 8 0.8 6.0 )(Page 1D-19)
Recoil starter mounting bolt 10 1.0 7.0 )(Page 1D-19)
TDC plug 23 2.3 16.5 )(Page 1D-19)
Spark plug 11 1.1 8.0 )(Page 1D-20)
Rocker arm shaft bolt 28 2.8 20 )(Page 1D-20)
Cylinder head cover bolt 10 1.0 7.3 )(Page 1D-29)
Crankcase bolt (M6)
11 1.1 8.0
)(Page 1D-46) /
)(Page 1D-53)
Crankcase bolt (M8)
26 2.6 19.0
)(Page 1D-46) /
)(Page 1D-53)
Oil pump drive gear bolt
80 8.0 58.0
)(Page 1D-47) /
)(Page 1D-54)
Speedometer gearbox bolt
10 1.0 7.0
)(Page 1D-49) /
)(Page 1D-57)
Starter cup nut
38 3.8 27.5
)(Page 1D-49) /
)(Page 1D-57)
Generator rotor nut 140 14.0 101.0 )(Page 1D-53)
Transfer gearshift cam stopper bolt 22 2.2 16.0 )(Page 1D-57)
Material SUZUKI recommended product or Specification Note
Grease SUZUKI SUPER GREASE A or
equivalent
P/No.: 99000–25010 )(Page 1D-18) /
)(Page 1D-49) /
)(Page 1D-49) /
)(Page 1D-57) /
)(Page 1D-57) /
)(Page 1D-66) /
)(Page 1D-67)
Molybdenum oil MOLYBDENUM OIL SOLUTION — )(Page 1D-13) /
)(Page 1D-22) /
)(Page 1D-23)
