Sveaverken F100 Auto Steer System Software User Manual
Figure 111.
Set the turnaround mode
Basic U-turn Turn around Mode
The turnaround path is Ω-
shaped. The turnaround is
easy and simple, and applies
to scenarios with sufficient
space for turning around.
The turnaround path is fish
tail shaped. It saves the
turnaround space, and is
applicable to scenarios with
limited turnaround space.
Manual switching of forward
and reverse gears is required.
Note:
1. When the working width is greater than twice of the turning radius, the final turnaround path is
U shaped.
2. As reversing is required for turnaround mode ②, this mode is only applicable when mounted
implements are used, or the implements might be damaged.
3. To adjust the safety distance for turning around, change the
Reserved Safety Distance
in
