AMI INSPECTOR pH
Instrument Setup
A-96.250.761 / 161017 23
4. Instrument Setup
4.1. Establish Sample Flow
1 Open sample flow tap.
2 Wait until the flow cell is completely filled.
3 Switch on power.
4.2. Programming
Programming Set all necessary sensor parameters in menu 5.1 Installation/Sen-
sors, further information see 5.1 Sensors, S. 54:
Type of sensor: set type of sensor to pH.
Flow measurement: Set the flow measurement to Q-flow.
Temperature: set Temp. Sensor to yes
Standards: Program the buffer values (pH buffer table) if you
do not use the SWAN standards.
NOTICE: The standards must be ordered separately.
Program all parameters for instrument operation (limits, alarms).
See Program Overview, S. 45, for explanations, see Program List
and Explanations, S. 50.
Calibration of
pH electrode
The instrument should be operating for 1 h before performing a pH
calibration.
Calibrate the pH electrode with two buffers, e.g. pH 7.00 and
pH 9.00. See Calibration, S. 31, for details.
