54 A-96.250.761 / 161017
AMI INSPECTOR pH
Program List and Explanations
5 Installation
5.1 Sensors
5.1.1 Flow
5.1.1.1 Flow measurement: Select the type of flow sensor if a flow sensor
is installed.
Possible flow sensors: None; Q-Flow; deltaT
5.1.2 Parameters:
5.1.2.1 Type of Sensor: Set the type of installed sensor.
Possible types: pH or Redox
5.1.2.2 Sensor Check: Not yet implemented. Set to off.
5.1.3 Temperature:
5.1.3.1 Temp. Sensor: The pH measurement is temperature dependent
therefore it is possible to install a temperature sensor.
Possible settings:
Temp. Sensor; <yes>, <no>
If <no> is set the measuring value is compensated with the default
temperature.
5.1.3.21 Default Temp.: If no temperature sensor is installed, set the default
temperature to the assumed average temperature of the sample.
The measuring value is then compensated with this value.
5.1.3.3 Temp. Compensation (only available for pH measurement)
5.1.3.3.1 Comp.: Choose the compensation model which fits best to your ap-
plication.
Available compensation models: Nernst, non-linear, coefficient.
We recommend: Nernst compensation for potable water, waste wa-
ter, swimming pools, non-linear or coefficient for high purity water.
5.1.40 Standards: A temperature curve is programmed for SWAN stan-
dard 1, pH 7 and SWAN standard 2, pH 9. If you want to use your
own standards you can readjust the temperature curve according to
your standards.
5.1.5.1 Standard 1: Assign the measured pH value to the according tem-
perature from 0–50 °C in steps of 5 °C.
5.1.5.2 Standard 2: Assign the measured pH value to the according tem-
perature from 0–50 °C in steps of 5 °C.
5.1.5.3 Standard: Enter the mV value of the redox standard.
5.1.5 Quality Assurance:
Not applicable.
