AMI INSPECTOR pH
Program List and Explanations
A-96.250.761 / 161017 55
5.2 Signal Outputs
5.2.1 Signal Output 3 (signal outputs 1 and 2 are deactivated)
5.2.1.1 Parameter: Assign one of the process values to the signal output.
Available values:
Meas. Value
Temperature
Sample Flow (if a flow sensor is selected)
5.2.1.2 Current Loop: Select the current range of the signal output.
Make sure the connected device works with the same current
range.
Available ranges: 0–20 mA or 4–20 mA
5.2.1.3 Function: Define if the signal output is used to transmit a process
value or to drive a control unit. Available functions are:
Linear, bilinear or logarithmic for process values.
See As process values, p. 56
Control upwards or control downwards for controllers.
See As control output, p. 57
