Swann AMI INSPECTOR pH - Error List

40 A-96.250.761 / 161017
AMI INSPECTOR pH
Maintenance
6.7. Replacing the Battery
1 Switch the AMI Inspector off.
2 If connected, disconnect the power adapter from the power
jack.
3 Open the transmitter housing.
4 Pull out the ribbon cable [C] from the mainboard.
5 Disconnect battery plug [B] and replace the battery.
A
B
C
Battery
Battery plug
Ribbon cable
CBA
