50 A-96.250.761 / 161017
AMI INSPECTOR pH
Program List and Explanations
9. Program List and Explanations
1 Messages
1.1 Pending Errors
1.1.5 Provides the list of active errors with their status (active,
acknowledged). If an active error is acknowledged, the alarm relay
is active again. Cleared errors are moved to the Message list.
1.2 Message List
1.2.1 Shows the error history: Error code, date / time of issue and status
(active, acknowledged, cleared). 65 errors are memorized. Then
the oldest error is cleared to save the newest error (circular buffer).
2 Diagnostics
In diagnostics mode, the values can only be viewed, not modified.
2.1 Identification
Desig.: Designation of the instrument.
Version: Firmware of instrument (e.g. V6.00-10/15)
2.1.3 Factory Test: Test date of the Instrument and Motherboard
2.1.4 Operating Time: Years / Days / Hours / Minutes / Seconds
2.2 Sensors
2.2.1 Electrode:
Current value: Shows the actual measuring value in pH or mV.
Raw value: Shows the actual measuring value in mV.
2.2.1.5 Cal. History: Review diagnostic values of the last calibrations.
pH: Number; Date, Time, Offset, Slope
or
mV: Number; Date, Time, Offset,
Max. 64 data records are memorized. One process calibration
corresponds to one data record:
2.2.2 Miscellaneous:
2.2.2.1 Case Temp: Shows the actual temperature in [°C] inside the
transmitter.
