70 A-96.250.761 / 161017
AMI INSPECTOR pH
Default Values
Relay 1/2 Function: .......................................................................... limit upper
Parameter: .................................................................... Meas. Value
Setpoint:............................................................. 14.00 pH/1500 mV
Hysteresis: ............................................................... 0.10 pH/10 mV
Delay:.....................................................................................30 Sec
If Function = Control upw. or dnw:
Parameter: .................................................................... Meas. Value
Settings: Actuator: ...........................................................Frequency
Settings: Pulse Frequency: ............................................ 120/min.
Settings: Control Parameters: Setpoint: ......... 14.00 pH/1000 mV
Settings: Control Parameters: P-band:................. 0.10 pH/10 mV
Settings: Control Parameters: Reset time: ...........................0 Sec
Settings: Control Parameters: Derivative Time: ...................0 Sec
Settings: Control Parameters: Control Timeout:..................0Min.
Settings: Act. ..................................................................Time prop.:
Cycle time: ............................................................................. 60 s
Response time: ..................................................................... 10 s
Settings: Act. ................................................................ Motor valve:
Run time: ............................................................................... 60 s
Neutral zone: ...........................................................................5%
If Function = Timer:
Mode:.................................................................................... Interval
Interval:................................................................................. 1 min
Mode: ....................................................................................... daily
Start time: ........................................................................00.00.00
Mode:.....................................................................................weekly
Calendar; Start time: .......................................................00.00.00
Calendar; Monday to Sunday: .................................................. Off
Run time: ...............................................................................10 Sec
Delay:.......................................................................................5 Sec
Signal output:............................................................................. cont
Output/Control: ......................................................................... cont.
Input: Active ............................................................................when closed
Signal Outputs ........................................................................... hold
Output/Control ..............................................................................off
Fault..............................................................................................no
Delay......................................................................................10 Sec
