LEFT-HAND SIDE VIEW
1) Side stand
2) Front brake disc
3) Front brake calliper
4) Gear shift pedal
5) Horn
6) Fuse control unit
7) Rider seat
8) Passenger seat/Storage compartment
9) Transmission chain
10) Coolant radiator.
11) Plate lighting device
12) Passenger handle
13) Cooling fan
