27- EN
CLUTCH CONTROL
The clutch control lever (1) is located on the left-
hand side of the handlebar and is equipped with
a protection.
The clutch control position on the handlebar can
be adjusted by loosening the retaining screws (2).
CAUTION
Do not forget to tighten the screws (2) after
adjustment.
REAR BRAKE CONTROL
The rear brake control pedal (1) is placed on the
right-hand side of the motorcycle. A stop switch,
during the braking action, causes the stop light on
the tail light to come on.
GEAR SHIFT CONTROL
The lever (1) is placed on the left-hand side of the
engine.
The rider must release the lever after each gear
change to allow it to return to its central position.
Neutral position (N) is between the first and
second gears.
First gear is engaged by pushing the lever
downwards; the other gears are engaged in a
sequence by pushing the lever upwards.
The lever position on the shaft can be changed.
To carry out this operation, loosen the screw, pull
the lever out, and place it in a new position on the
shaft.
Tighten the screw once operation is completed.
CAUTION
Do not downshift when travelling at a speed that
would force the engine to “overrev” or cause the
rear wheel to lose grip, if the immediately lower
gear is selected.
WARNING
Do not shift gears without disengaging the clutch
and closing the throttle. The engine could be
damaged by “over-revving”.
