EN-40
ENGINE COOLANT LEVEL CHECK
The engine coolant level must be between the
MIN and MAX notches on the clear reservoir (1).
The coolant level check must be carried out with
engine cold and motorcycle perpendicular to
the ground.
If topping up is required, unscrew the plug (2)
and pour coolant through the filler neck.
It is also necessary to restore the level in the res-
ervoir (1).
CAUTION
With engine hot, do not remove the reservoir
plug, risk of burns!
AIR FILTER CHECK AND/OR REPLACEMENT
- Remove the front fairing by unscrewing the re-
taining screws (2) (one per side) and the screws
(1).
- Unscrew the screw (3) and remove the filter
cover (4).
- Remove the filter (5) and check its condition; to
clean it, blow it with compressed air; if it is very
dirty, replace it.
- Refit all components following removal opera-
tions in reverse order.
