CONTROLS
IGNITION SWITCH
The ignition switch has three positions:
Motorcycle start position (key not remova-
ble);
Key removal position;
Steering lock position (key removable).
-Key removal position " "
Turning the key to position , the engine and
the lights go off and you can remove the key from
the ignition block.
-Start position" "
From the key removal position , turn the key
(1) clockwise to the start position ; the lights
and the display will come and you can start the
motorcycle.
STEERING LOCK
The motorcycle comes with a steering lock
located on the ignition switch (1) Lock the steering
as follows:
-Turn the handlebar to the left.
-Insert key (2) in the ignition switch (1) set to .
-Press the key in (2) and turn it anticlockwise to
position .
-Remove the key (2).
To unlock the steering lock, reverse the above
procedure.
RH HANDLEBAR SWITCH
The right-hand switch features the following con-
trols:
1) Engine start button
Pressing the button (1) with the key in position
and the switch (2) in position, the engine
starts.
2) Engine KILL SWITCH.
Flicked to position, disables engine starting
and running.
Flicked to position, enables engine starting and
running.
2
1
