VIEWS OF MOTORCYCLES
6
7
4
3
1
2
5
8
12
11
13
10
9
14
15
16
RIGHT-HAND SIDE VIEW
1) Fuel tank cap
2) Fuel tank
3) Instrument panel
4) Headlight
5) Taillight
6) Front turning indicators
7) Rear turning indicators
8) Rear brake disc
9) Rear brake calliper
10) Combined braking control pedal
11) Rear brake pump
12) Engine oil filter
13) Engine oil dipstick
14) Throttle body
15) ABS control unit.
16) Coolant recovery tank
