SWM VAREZ - Projector Bulb Replacement; Taillight Bulb Replacement; Plate Light; Plate Light Bulb Replacement

EN-58
PROJECTOR BULB REPLACEMENT
-The front projector (1) is the LED type, replace it
if it does not work.
TAILLIGHT BULB REPLACEMENT / PLATE
LIGHT
-The tail light (2) is of LED type, if it does not work,
replace it.
PLATE LIGHT BULB REPLACEMENT
To replace the plate light, proceed as follows:
-Remove the plate by releasing it from the side
fastening devices;
-Disassemble the plate by removing the screws
(3) and their nuts (5);
-Unscrew and remove screws (1) and (6);
WARNING
Do not unscrew screws (2) and (4)
-Lift the cover (7) and remove the lamp holder
(8);
-Replace the 5W lamp with a new one, removing
it from its lamp holder;
For refitting, repeat the operations described in
reverseorder.
2
3
4
5
1
6
7
8
