EN-12
SECONDARY DRIVE
Transmission sprocket …………………………………………………………………………………Z 14
Rear wheel sprocket ……………………………………………………………………………………Z 53
Transmission ratio ………………………………………………………………………………………3.786
Transmission chain dimensions. ………………………………………………………4/8" x 7/20"
CHASSIS
Type …………………trellis perimeter frame made of high-resistance steel tubes
FRONT SUSPENSION
Type …………………………………………tele-hydraulic with inverted fork legs Ø 41 mm
REAR SUSPENSION
Type…………………………single hydraulic shock absorber (adjustable in pre-load)
FRONT BRAKE
Type……………fixed disc Ø 300 mm. With hydraulic control and floating caliper
REAR BRAKE
Type ........................fixed Ø220 disc with hydraulic control and floating caliper
RIMS
Front …………………………………………………………………………………in light alloy: 3.00”x17”
Rear……………………………………………………………………………………in light alloy: 4.50”x17”
TYRES
Front …………………………………………………………………………………………………110/70 -17"
Rear……………………………………………………………………………………………………140/70 -17"
Cold tyre pressure
Front
Rider only …………………………………………………………………………………………………2.0 bar
Rider and passenger …………………………………………………………………………………2.0 bar
Rear
Rider only …………………………………………………………………………………………………2.2 bar
Rider and passenger …………………………………………………………………………………2.4 bar
DIMENSION, WEIGHT, CAPACITY
Wheelbase ……………………………………………………………………………………………1350 mm.
Overall length ………………………………………………………………………………………2020mm.
Overall width……………………………………………………………………………………………810mm.
Overall height ………………………………………………………………………………………1070mm.
Saddle height …………………………………………………………………………………………840 mm.
Dry weight............................................................................................................... 149kg
Fuel tank capacity.................................................................................................... 13.5 l
Coolant capacity.............................................................................................. 1.1-1.3 l
Transmission oil
Oil and oil filter replacement.................................................................................1.5 l
Oil replacement ...................................................................................................... 1.35 l
Homologation ......................................................................................................EURO 5
