SWM VAREZ - Page 55

EN-54
Cable Colour Coding
B………………………………………………………………………Blue
B/Y ………………………………………………………Blue/Yellow
B/Gr ……………………………………………………Blue /Grey
Bk………………………………………………………………… Black
Bk/R…………………………………………………… Black /Red
Bk/O……………………………………………… Black / Orange
Bk/Br……………………………………………… Black / Brown
Bk /Y………………………………………………… Black /Yellow
Br …………………………………………………………………Brown
Br/R…………………………………………………… Brown/Red
Br/W………………………………………………… Brown/White
Br/Y………………………………………………… Brown/Yellow
Br/ Bk……………………………………………… Brown/ Black
B/W…………………………………………………… Blue / White
G …………………………………………………………………Green
G/B …………………………………………………Green/ Blue
G/Bk …………………………………………………Green/Black
G/Gr…………………………………………………… Green/Grey
G/O……………………………………………… Green/Orange
Gr ……………………………………………………………………Grey
G/W …………………………………………………Green/White
Lg /R………………………………………… Light Green /Red
Lb …………………………………………………………Light Blue
Lg ………………………………………………………Light Green
Lg/R……………………………………………Light Green/ Red
O……………………………………………………………… Orange
O/Bk……………………………………………… Orange/Black
O/Gr……………………………………………… Orange/ Grey
O/W……………………………………………… Orange/ White
R…………………………………………………………………… Red
R/ Bk ……………………………………………………Red / Black
W………………………………………………………………… White
W/Bk………………………………………………… White/Black
W/Br……………………………………………… White/ Brown
W/R ………………………………………………………White/Red
W/Y …………………………………………………White/Yellow
Y …………………………………………………………………Yellow
Y/W …………………………………………………Yellow /White
Y/Br…………………………………………………Yellow/ Brown
Y/R………………………………………………………Yellow/Red
Pk……………………………………………………………Pink
Pk/Bk……………………………………………………Pink/Black
P……………………………………………………………Purple
KEY TO WIRING DIAGRAM
1) Electronic power unit
2) OBD unit interface
3) Brake fluid filler
4) Starting motor
5) Start relay
6) Battery
7) Alternator
8) Voltage regulator
9) Power
10) Fuses
11) Clutch switch
12) Neutral switch
13) Relay fuel pump
14) RH Switch
15) Power relay
16) Fuel sensor
17) Fuel pump
18) Injector
19) HT coil
20) Lambda sensor
21) Solenoid valve
22) Front LH turning indicator
23) Headlight
