17
5 IN1 Park axis Rising edge
6 IN2 Start Program Rising edge
7 IN3 Start Calibration Rising edge
8 IN4 Remote Lock Persistent
9 IN5 Select Program 0 Persistent
10 IN6 Select Program 1 Persistent
11 IN7 Select Program 2 Persistent
12 IN8 Load Program Rising edge
13 IN9 Lock Tailstock Rising edge
14 IN10 Unlock Tailstock Rising edge
15 IN11 Reserve IN
16 IN12 Reserve IN
17 IN13 Reserve IN
18 IN14 Reserve IN
19 IN15 Reserve IN
20 IN16 Reserve IN
21 OUT1 Remote mode Persistent
22 OUT2 Machine Ready Persistent
23 OUT3 Is Calibrated Persistent
24 OUT4 Is Parked (SW) Persistent
25 OUT5 Tailstock Locked (SW) Persistent
26 OUT6 Tailstock Unlocked (SW) Persistent
27 OUT7 Loaded Program 0 Persistent
28 OUT8 Loaded Program 1 Persistent
29 OUT9 Loaded Program 2 Persistent
30 OUT10 Reserve OUT
31 OUT11 Result Ready Persistent
32 OUT12 No Result Persistent
33 OUT13 Pass Persistent
34 OUT14 Failed Persistent
35 OUT15 Warning Persistent
36 OUT16 Reserve OUT
37 Earth Shielding
