Sylvac SCAN S25 - Profinet Via Gateway; Configuration of the Local IP Address

26
8. PROFINET VIA GATEWAY
The Scan machine can be controlled by a Profinet bus using a gateway Moxa MGate 5103 that converts Mod-
busTCP<>Profinet I/O Device.
When RS+ software is installed, the configuration files needed for the gateway are copied to the disk in the
‘Resources\Profinet’ subdirectory of the Scan program.
The factory settings of the gateway are as follows :
The network card must be configured to be in the same ‘192.168.127.*’ subnet as the gateway and must match
the one used for Modbus TCP.
IP address 192.168.127.254
Login admin
Password moxa
8.1 Configuration of the local IP address
