7.4 Input table (Holding Register, Read-Write, FC3, FC6, FC16)
7.5 Output table (Discrete Input, Read-Only, FC2)
Variable Description Address Type Size
Program Id to Load ID of the program to be loaded 0 uint16 2 bytes
Program Name to Load Name of the program to be loaded 1 utf8[20] 20 bytes
Slide Target Position
Choose the position of the slide for
displacement [mm]
11 float32 4 bytes
Rotation Target Position
Choose the position of the rotation
for displacement [°]
13 float32 4 bytes
Tilt Target Position
Choose the position of the tilt for
displacement [°]
15 float32 4 bytes
Tailstock Target Position
Choose the position of the tailstock
for displacement [mm]
17 float32 4 bytes
Trace Field 1 Tracing field 1 20 utf8[20] 20 bytes
Trace Field 2 Tracing field 2 30 utf8[20] 20 bytes
Variable Description Address
Remote mode Scan in remote mode 0
Machine Ready Machine ready to receive a command 1
Is Calibrated Machine calibrated 2
Is Parked Machine parked 3
Is Tailstock Locked Tailstock closed 4
Is Tailstock Unlocked Tailstock open 5
Is Chuck Closed Chuck closed 6
Is Chuck Open Chuck open 7
Result Ready Measurement result available 8
No Result No measurement result 9
Pass Measurement result within tolerance 10
Failed Measurement result out of tolerance 11
Warning Measurement result within tolerance limit 12
Rework
Measurement result outside of tolerance, rework
possible
13
