2. SAFETY SYSTEM
The only safety element of Scan S25 is an emergency stop button with double signal.
When the emergency stop button is pressed, the electric power to the Scan is cut off, the motors are no longer
under power, the Scan S25 is in a fault condition.
To restore power to the Scan S25 and be able to continue the measurements, two actions are necessary (in this
order) :
1. Pull the emergency stop button (to restore the safety signals).
2. Start a measurement (from ReflexScan or from the touchscreen).
Emergency Stop
Button
2.1 Functioning of the safety system
