097-10603-01 Rev. A – November 2004 X72 Desiger’s Reference and User’s Guide 65
Using the Symmetricom Serial Interface Protocol
4 ACMOS Output
Enable
0 = Enable Output
1 = Disables Output
Default is set at Factory per Configuration file
that matches customer's selection – Host
can alter during operation, but host cannot
alter the default power up condition.
5* C-field Boost 0 = Low C-field
1 = High C-field
Controlled by firmware – an automated
function.
6 SINE Output
Enable
0 = Enables Output to
40% of max output
1 = Disables Output
Default is set at Factory per Configuration file
that matches customer's selection – Host
can disable SINE output, but host cannot
alter the default power up condition. Note: if
a SINE filter is not installed, SINE enable will
not provide an output.
7* SINE Output Level
Adjust 1
0 = Zero Level
1 = Adds 30% of max
Output
Controlled by firmware – set at factory.
8* SINE Output Level
Adjust 2
0 = Zero Level
1 = Adds 20% of max
Output
Controlled by firmware – set at factory.
9* SINE Output Level
Adjust 3
0 = Zero Level
1 = Adds 10% of max
Output
Controlled by firmware – set at factory.
10* SERVICE 0 = Unit is OK
1 = Unit requires Service
Controlled by firmware – Automated
Function.
11-15 Reserved – Not
Used.
* user cannot set
Note: When altering the Control Register these bits are masked out
by firmware, the Host will consider these bits as "DON'T CARE".
Table B-5. Output Control Status Register Structure (Continued)
Bit # Control Description Controller
