System Sensor PDRP-1001 User Manual

RMS Regulated Power
1 The PDRP-1001/PDRP-1001A/PDRP-1001E
The PDRP-1001 PN 50734:C 03/11/99 11
Figure 2 Cabinet Dimensions

Door = 14.625 in.
(371.48 mm)
Backbox = 14.5 in.
(368.3 mm)
Cabinet = 5.375 in.
(136.53 mm)
Backbox = 4.750 in.
(120.65 mm)
Door = 16.125 in.
(409.58 mm)
Backbox = 16 in.
(406.4 mm)
1.5 in
(38.1 mm)
16.094 in.
(408.79 mm)
14.594 in.
(370.69 mm)
TR-4XR
RUBY RD
STEEL
16 GA.
Optional Trim Ring
TR-4XR

System Sensor PDRP-1001 Specifications

General

Brand	System Sensor
Model	PDRP-1001
Category	Control Panel
Language	English
