3 Installation Procedure
Zone Relay Module - 4XZM (NOTIFIER)
24 The PDRP-1001 PN 50734:C 03/11/99
Zone Relay Module - 4XZM (NOTIFIER)
Non-power limited and power limited wiring must have a minimum distance of 0.25 in.
(6.35 mm) wire to wire. If this module is used to drive non-power limited and power
limited circuits, please follow the instructions below.
1) Skip a set of dry contacts to maintain the 0.25 in (6.35 mm) required space
between power limited and non-power limited circuits. The wiring of this module must
follow the requirements as specified in the “
General
” section, “
UL Power Limited
Wiring Requirements
.”
OR
2) If this module is needed to drive power limited and non-power limited relays that
are next to each other, refer to the figure below showing a typical connection.
Relay #1 through #4 will activate with Output #1 through #4
and remain latched unless jumper “LATCH” is cut.
1 NO
2 NC
3 C
4 NO
5 NC
6 C
7 NO
8 NC
9 C
10 NO
11 NC
12 C
13 NO
14 NC
15 C
16 NO
17 NC
18 C
Relay #1
Relay #2
Relay #3
Relay #4
Alarm
Trouble
Cut jumper for non-latching (silenceable) relay operation.
Use Disable switch to disconnect the relays.
Note: Refer to the Protected Premises Unit label, located on the door of the control panel, to
indicate if any dry contacts are to be used as non-power limited dry contacts.
Relay #1
Relay #2
Relay #3
Relay #4
NO
NC
C
NO
NC
C
NO
NC
C
NO
NC
C
Power Limited Circuit
Power Limited Circuit
No Connection
Non-power Limited Circuit
Non-power Limited Circuit
To Next Page
