Basic Program
3 Installation Procedure
The PDRP-1001 PN 50734:C 03/11/99 27
Setting Mode of Operation
Basic Program
Select the desired mode of operation and set SW1 DIP switches 1 and 2 per the
appropriate column.
Note: Zones 1 and 2 refer to Initiating Device Circuits 1 and 2.
Discharge Timer
Select the desired Discharge Timer setting by setting SW1 DIP switches 3, 4 and 5.
For NFPA 13 and 15 applications, Timer must be set to DISABLED.
For NFPA 16 applications, Timer may be set to 10 MINUTES or 15 MINUTES.
Note:
Discharge Timer:
1) Timer will always start at Zone 2 normal to alarm transition. Upon time-out, corresponding release circuits
will shut off.
2) Zone 1 will always override timer shutoff (except for Mode #4 - Split Release).
MODE #1
Single Hazard
Two Zone
MODE #2
Single Hazard
Cross Zone
MODE #3
Dual Hazard
Combined Release
MODE #4
Dual Hazard
Split Release
Switch 1
Switch 2
OFF
OFF
ON
OFF
OFF
ON
ON
ON
Outputs 1 and 3
-
activated by an alarm on
either Zone
1
or
2
.
Output 2
-activated by a
waterflow alarm on
Zone 3
.
Output 4
-activated by a
supervisory condition on
Zone 4
.
Output 1
-activated by an
alarm on either
Zone 1
or
Zone 2
.
Output 2
-activated by a
waterflow alarm on
Zone 3
.
Output 3
-activated by
alarms on both Zone 1
and
Zone 2
.
Output 4
-activated by a
supervisory condition on
Zone 4
.
Output 1
-activated by an
alarm on either
Zone 1
or
Zone 2
or a waterflow
alarm on
Zone 3
.
Output 2
-activated by a
supervisory condition on
Zone 4
.
Output 3 and 4
-
activated by an alarm on
either
Zone 1
or
Zone 2
.
Output 1
-activated by
an alarm on either
Zone
1
or
Zone 2
or a
waterflow alarm on
Zone 3
.
Output 2
-activated by a
supervisory condition on
Zone 4
.
Output 3
-activated by
an alarm on
Zone 1
.
Output 4
-activated by
an alarm on
Zone 2
.
Disabled 10 Minutes 15 Minutes
Switch 3
Switch 4
Switch 5
OFF
OFF
OFF
ON
ON
OFF
ON
ON
ON
