Fig.1,2and6
BydeliveryofaDVCmodulewith
dividedrotor,themotorisinstalled
beforedeliverytothecustomer


Fig.2
Thedrivebeltmustbeplacedaround
therotorandtheidealdistanceis9
cmfromthe2sidesoftherotor.The
rotorsarealways20cmthick.The
distancetothedrivebeltfromaside
oftherotormustbebetween9–11
cm.the2sidesof
therotor.
Fig.3,4and5
Motorismountedonthemotor
consoleplateand4shockabsorbers
aremountedundertheplatewith
M8bolts.

Fig.2
Fig.3
Fig.4
Fig.5
Fig.6
