Editing Configuration Profiles I/NET Configuration
4-8 I/NET 2000 Getting Started
Link Type is Embedded 4.x Dial
Embedded 4.x Dial allows the host workstation to emulate the
78041 Tap. You must have a modem installed under Windows.
Note: Refer to the “Communication” chapter in TCON237, I/NET 2000
Technical Reference Guide for additional information on Embedded
4.x Dial.
1. Set the
Link type to Embedded 4x Dial.
2. Select the modem from the list of available TAPI devices in
the
Port or devices drop-down list.
3. Since the baud rate is controlled by Windows, the
Baud rate
parameter is not applicable.
4.
Add a link in the Link summary:
a. Set the
Hardware address to 0.
b. Set the
System address to a number from 0–99. This
address must be unique for each link within the system.
c. Enter a
Name for the link.
d. The
Dial link checkbox is activated automatically.
e. Click
OK.
5. The Embedded 4.x Dial function supports “multi-link dial.”
Repeat Step 4 to define additional links. Refer to the
“Communication” chapter in TCON237, I/NET 2000 Tech-
nical Reference Guide for information on multi-link dial.
6. Proceed to “TCP/IP Parameters” on page 4-9.
Link Type is Integrated Dial or Integrated NPR Dial.
The only difference between Integrated Dial and Integrated NPR
Dial is that Integrated NPR Dial is used to call an NPR. The param-
eter settings are the same. Ensure that you have installed a modem
under Windows prior to choosing either of these settings.
1. Set the
Link type to Integrated Dial or Integrated NPR Dial.
2. Select a modem from the
Port or device drop-down list.
