Takagi T-H3-DV Service Handbook

COMPONENTS
COMPONENTS
On-Demand Water Heater Service Handbook for 240, 340 & 540 Condensing Models • 75
COMPONENTS
COMPONENTS
COMPONENT ITEM NUMBERS
Item #
Part #
Description
240, 340,
and 540
models
T-H3J,
T-H3S
and T-H3
models
001
N/A EK159 Case assembly for Indoor model
N/A EK164 Case assembly for Outdoor model
002
100074663 EK187 Front cover for 240 and 340 Indoor (T-H3J-DV and T-H3S-DV)
100074664 EK188 Front cover for 240 and 340 Outdoor (T-H3J-DV and T-H3S-OS)
100074665 EK158 Front cover for 540 Indoor (T-H3-DV)
100074666 EK174 Front cover for 540 Outdoor (T-H3-OS)
003 100074667 EK170 Intake air port assembly
004 N/A EK162 Bracket
005 100074668 EK190 Junction box for Outdoor model
006 100074669 EK171 Power supply cord assembly
007 N/A EK161 Back guard panel
008 N/A EK160 Chamber fixing plate
009 100074203 EKH23 Condensate drain port
050 N/A EW000 Truss screw M4x12 (w/ washer) SUS410
051 N/A EW001 Truss screw M4x10 (w/ washer) SUS410
052 N/A EW002 Truss screw M4x10 (Coated) SUS3
053 N/A EW003 Truss screw M4x10 SUS
054 N/A EW004 Hex head screw M4×12 (W/Washer) SUS3
055 N/A EW005 Hex Head screw M4x8 FeZn
056 N/A EW018 Pan screw M4x20 SUS410
057 N/A EKK31 Tap tight screw M4x12 FeZn
058 N/A EW00A Tapping screw M3x6 SUS3 Binding head
059 N/A EW009 Tapping screw M4x6 SUS3 Truss head
060 N/A EKK37 Screw M4x12
061 N/A EK191 Screw M3x6
062 N/A EW00D Pan screw M4x8 MFZN
063 N/A EM167 Wire clamp 60
064 N/A EK230 Screw M4x10
065 N/A EW00B Screw M3x6 SUS3 binding head
101 100074670 EK192 Burner assembly
102
100074671 EK181 Manifold with gas valve assembly LP
100074672 EK182 Manifold with gas valve assembly NA
