Takeuchi TB014 User Manual

100
MAINTENANCE
Service Data
Tools
No. Part name
Part No.
Remarks Part nameNo. Part No. Remarks
1 Spanner 19102-12081 10-12 <TB014>
1 Spanner 19100-47081 10-12 <TB016>
2 Spanner 19102-12082 12-14 <TB014>
3 Spanner 19102-12083 13-17 <TB014>
3 Spanner 19100-47082 14-17 <TB016>
4 Socket wrench 19102-12084 19-22 <TB014>
5 Screwdriver 19102-12085 (+) (–) <TB014>
5 Screwdriver 19100-06112 (+) (–) <TB016>
6 Filter wrench 03392-22610 < TB014 >
7 Filter wrench
19100-96081 < TB016 >
8
Monkey wrench 16904-00250 250mm
9 Spanner
16901-00013 13
10 Spanner
16900-01922 19-22
11 Spanner
16909-00026 26
12 Pliers
16905-00200 200mm
13 Grease gun
16910-60600 600cc
14 Tool case
16914-00001
15 Drain connector 15545-12201 for EU

Takeuchi TB014 Specifications

General

Engine	Yanmar 3TNV70
Overall Width	980 mm
Transport Width	980 mm
Bucket Capacity	0.04 m3
Max Digging Depth	2260 mm
