143
TROUBLESHOOTING
If a Warning Lamp Lights
If an alarm is sounded or a warning lamp starts flashing during operation, park the machine
in a safe place and perform the procedures described below.
Warning lamp Lamp name Procedure
The coolant temperature has risen irregularly and the
engine is overheating.
Refer to page 139 “If the Engine Overheats”.
Engine
emergency
lamp (TB016)
A problem has occurred in the engine lubrication system
or the coolant water temperature has risen irregularly.
¡ When there is a problem in the engine lubrication
system, the engine oil pressure warning lamp flashes
simultaneously.
¡ When the coolant water temperature has risen
irregularly, the coolant temperature warning lamp
flashes simultaneously.
For the procedures, refer to the respective warning lamps
below.
Battery charge
warning lamp
There is a problem with the fan belt or charger. Inspect
the fan belt for slack or breakage and adjust as necessary.
If the lamp continues flashing or lights after maintenance,
there is a problem with the charger. Consult a Takeuchi
sales or service outlet.
Refer to page 114 “Inspecting and Adjusting the Fan Belt”.
Engine oil
pressure
warning lamp
Inspect the engine oil level. If the lamp is flashing or lit
even though the level is normal or if it continues flashing
or lights after oil is added, consult a Takeuchi sales or
service outlet.
Refer to page 108 “Inspecting and Replenishing the
Engine Oil”.
Coolant
temperature
warning lamp
SK2-121
OSOB080
OSOB070
C
4B
0
12

Takeuchi TB014 Specifications

General

Engine	Yanmar 3TNV70
Overall Width	980 mm
Transport Width	980 mm
Bucket Capacity	0.04 m3
Max Digging Depth	2260 mm
