INTRODUCTION
Foreword
This manual describes operation, inspection and maintenance of the machine, as well as
safety instructions to be heeded during these operations.
If you have any questions about the machine, please contact a Takeuchi sales or service
outlet.
■ Manual storage compartment
A compartment for storing this manual is
provided at the position shown on the
diagram below.
1. Insert the starter key and turn it
counterclockwise to unlock the manual
storage compartment.
2. After using the manual, place it in the
plastic pouch and store it back in the
manual storage compartment.
■ Serial numbers
Check the serial numbers of the machine and
the engine and write them in the spaces
provided below.
Machine number :
Engine number :
< TB014 >
< TB016 >
C4A006
C4B003

Takeuchi TB014 Specifications

General

Engine	Yanmar 3TNV70
Overall Width	980 mm
Transport Width	980 mm
Bucket Capacity	0.04 m3
Max Digging Depth	2260 mm
